Seal-Guard™
Premium Thread Compound - Environmental Formula

Specifically formulated to meet the performance requirements of proprietary, metal-to-metal seal, and high interference connection designs utilizing today's high performance materials including super chrome and high alloy steels. SEAL-GUARD's formulation uses a tightly controlled small particle size distribution and may not provide optimum sealability on buttress thread forms.

SEAL-GUARD is formulated using an advanced base grease and additive technology (CZ-EX PLUS) with enhanced high and low strength polymers and innovative solid lubricants. The result is superior lubrication under high loads with galling resistance equivalent to heavy metal based compounds in a totally metal free formulation. This cutting edge technology provides a high affinity to metal surfaces with a relatively low added solids content. This formula has a large percentage of submicron particles that create a film which gives consistent frictional performance without restricting proper engagement of the connection.

- Recommended for use on premium mechanical seal an 8-round connection, flow lines, nuts, bolts, etc. Can be utilized on jacking systems.

Benefits

  • Advanced base grease and additive technology
  • Enhanced high & low strength polymers
  • High film strength protects against galling
  • Small particle solids to accommodate premium connection design requirements
  • Metal-free
  • H₂S inhibitor
  • Sticks to wet or oily threads
  • Environmentally safe

Specifications

  • Base Materials
    • Complex / Petroleum
  • Friction /
    Nut-Factor
    • 1.0 (Relative to API MODIFIED)
  • Certifications
    • Ospar Commission – Harmonized Offshore Chemical Notification Format (HOCNF) CLASSIFICATION: “Red” rating for Norway CLASSIFICATION: “D” for The United Kingdom and The Netherlands
    • Conforms to or exceeds the requirements for API RP5A3/ISO 13678 specification
  • Service Rating
    • -20°F to 450°F
    • -29°C to 232°C

Product Numbers

United States

  • 14429 - 50-55 GAL Drum - 450 LB
  • 14415 - 5 GAL Pail - 44 LB
  • 14423 - 1 GAL Pail - 9 LB
  • 14415L - 5 GAL Pail (w/Liner) - 44 LB
  • 14417 - 5 GAL Pail (Metal) - 44 LB
  • 14412 - 2 GAL Pail - 18 LB

United Kingdom

  • JA14429 - 50-55 GAL Drum - 204.12 KG
  • JA14415 - 5 GAL Pail - 20 KG
  • JA14423 - 1 GAL Pail - 4.08 KG
  • JA14415L - 5 GAL Pail (w/Liner) - 20 KG
  • JA14417 - 5 GAL Pail (Metal) - 20 KG
  • JA14412 - 2 GAL Pail - 8 KG

Canada

  • 14429CA - 50-55 GAL Drum - 204.12 KG
  • 14415CA - 5 GAL Pail - 20 KG
  • 14423CA - 1 GAL Pail - 4.08 KG
  • 14415LCA - 5 GAL Pail (w/Liner) - 20 KG
  • 14417CA - 5 GAL Pail (Metal) - 20 KG
  • 14412CA - 2 GAL Pail - 8 KG
